Are all fluorescent tubes the same

All fluorescent lamps use the same technology, but there are several different variations and sizes.

How do I know what fluorescent tube I have?

In order to identify which size you need, the easiest way to tell is to read the label near the base of the tube. If this information is no longer legible, you can measure the bulb’s diameter. Fluorescent tubes are measured in eighths of an inch.

What are the 3 types of regular fluorescent lamp?

• T12 bulbs are the oldest type still in use in some fluorescent fixtures. …
• T8 bulbs are more expensive than T12 bulbs but will start much faster. …
• T5 bulbs are a smaller version of their big brothers.

Are fluorescent tubes interchangeable?

Even though the fluorescent light socket is exactly the same for both of them, they cannot operate on the same ballast. … So the bottom line is that these are not interchangeable and if you’re going to upgrade from a T12 to a T8 bulb, then you also have to change out the ballast.

What are the different sizes of fluorescent tubes?

While there are multiple types of LED and fluorescent tube lights, the three most common are T12, T8 and T5. The terminology comes from “T” for “tubular” and the diameter of the bulb in eighths of an inch, so “T8” represents a tube of 8/8ths of an inch, or 1 inch.

Can I replace my fluorescent tubes with LED?

Yes, you can replace fluorescent tubes with LED tubes or LED-integrated fixtures. If you just want to replace the bulbs, you can use plug-and-play, direct-wire, or hybrid LED tubes. Plug-and-play tubes are the easiest to install as they do not require any rewiring to the fixture.

How do I know if I have T8 or T12?

If no markings are available, the size in diameter of the tube is the easiest way to determine the type you have installed. T8 tubes are 1-inch in diameter and T12 tubes are 1 1/2 -inch.

Can I use T8 instead of T12?

T8 tubes are simply 1 inch in diameter versus the 1.5 inch diameter of T12 tubes. In an effort to make LED tube lights compatible with the internal dimensions of most fixtures, you will find that most LED tube lights feature a T8 or 1 inch diameter. They can indeed be used in T12 fixtures.

Is my ballast T8 or T12?

Replace Current Lamp You will see either T8 or T12 stamped on one side near the end with the prongs. You also will see the lamp’s rated wattage, usually 32 watts for T8 and 40 watts for T12. Measure the diameter of the lamp. T12 lamps are larger than T8 lamps, with a 1 ½-inch diameter.

Can I replace T8 with LED?

Type A – LED tube has an Integrated Driver for use on Existing Fluorescent Ballast. Type A LED tubes need an existing T8 electronic ballast to operate. … All you need to do is remove the existing T8 fluorescent lamp and install a new T8 LED Type A lamp.

Article first time published on

Which is brighter incandescent or fluorescent?

Traditional incandescent light bulbs emit about 15 lumens per watt. So, to reach a brightness of 800 lumens, incandescent light bulbs will require 60 watts to power the light. … CFL’s or fluorescent light bulbs emit 60 lumens per watt. LED’s, however, are the most effective of all, with a whopping 72 lumens per watt.

Are all T8 bulbs the same?

Like T12 lamps, T8 lamps are available in a variety of color temperatures, including warm (3000 K), neutral (3500 K), cool (4100 K), and very cool (5000 K). … Color temperature may also be included in the designation by replac- ing the zero in the new designation with the first two digits of the CCT.

What is T5 fluorescent tubes?

A T5 is a type of fluorescent tube. It differs from a T12 and a T8 in its diameter. All T5s are 5/8ths of an inch (T8s are exactly 1inch thick and T12s are 12/8ths or 1.5 inches thick). T5s are 16mm in diameter making them the thinnest fluorescent tube out of the three.

What's better T5 or T8?

T5 lamps are smaller and more efficient than T8 bulbs. T5 lights are the winner between the two, they do cost about 2x more than T8 options. While T8s are cheaper upfront, T5s are a more affordable option long-term and are great for most growing needs.

Which is better LED or fluorescent?

LED tube lighting is the better choice because it lasts about 40,000 hours longer in testing, is more energy efficient, will save you more money, and will leave less impact on the environment.

What is the difference between LED and fluorescent lights?

The main difference between a fluorescent and an LED is their energy usage and lifespan. Fluorescent lights last around 10, 000 hours before it is required to be replaced. … These lights can range in sizes. When it comes to energy efficiency, LED lights are around 5 times more efficient than fluorescent lights.

How do I know what ballast to buy?

It needs to fit the electrical requirements of the lamp that it will run. When purchasing a ballast, you’ll need to read the type of lamps it’s designed for, how many lamps it operates, and the voltage the lamps will run on. Choosing the right ballast for a lamp will optimize the light output and life of the bulb.

Are T12 bulbs being discontinued?

In effect since July 2012, the legislation eliminates nearly all 4-foot T12 lamps, some 4-foot T8 lamps, most 8-foot T12 lamps, and almost all standard halogen PAR38, PAR30 and PAR20 lamps from the market. T12 technology is over 80 years old. Since that time, lamps and bulbs have been developed that just work better.

Should a fluorescent ballast get hot?

Overheating ballasts often exhibit symptoms. They may cause the bulb to flicker, shine, dim, or not work at all. … A further test would be to check for heat from the ballast. Ballasts usually run hot, about 140 degrees F, but if one is so hot that you can’t keep your hands on it, it is likely the culprit.

Can you use a 2 lamp ballast for 1 lamp?

A 1 lamp rapid start (series) ballast can be hard to find, but it can be replaced with a 2 lamp instant start (parallel) ballast.

Can you put a T8 LED bulb in a T12 fixture?

T8 tubes are simply 1 inch in diameter versus the 1.5 inch diameter of T12 tubes. In an effort to make LED tube lights compatible with the internal dimensions of most fixtures, you will find that most LED tube lights feature a T8 or 1 inch diameter. They can indeed be used in T12 fixtures.

Are LED lights brighter than fluorescent?

The LED tube lights are noticeably brighter than fluorescent tubes and you don’t get exposed to any kind of harmful rays such as UV/IV rays as well that can damage your eyes and can result in skin allergies as well.

Do I need to remove ballast for LED lights?

A plug and play LED is a fixture where you can install LED bulbs to what was once a fluorescent bulb. This is an easy solution and requires minimal effort on your part. Since it works with the existing ballast, there is no need for rewiring or ballast removal.

Are T8 LED bulbs worth it?

They are not only more efficient than all other forms of commercially available lighting. They are far more efficient than all other forms, and that racks up over time. You could save a lot of money on energy by replacing your fluorescent bulbs with LEDs.

Why are fluorescent lights bad?

The Bad: Fluorescent tubes & CFL bulbs contain a small amount of mercury gas (about 4 mg) – which is toxic to our nervous system, lungs and kidneys. So long as bulbs stay intact, the mercury gas is no threat.

Do fluorescent lights use more electricity?

Fluorescent lamps, including compact fluorescent lights (CFLs), use about 75 percent less energy than incandescent bulbs and last six to 15 times as long, according to the U.S. Department of Energy (DOE). … Otherwise, turn the light off.

Do LED lights use less power than fluorescent?

Other advantages of LEDs over fluorescent lights: Last longer — LED bulbs last up to several times (10 times) more than the compact fluorescents, and far longer than typical incandescent bulbs. … More efficient – LED light bulbs use only 2-17 watts of electricity (1/3rd to 1/30th of Incandescent or CFL).

What's the difference between T5 and T8 LED tubes?

The major physical difference between T5 and T8 light bulbs is the length and diameter of the tube itself. The T5 tends to be slightly shorter than the T8 tube, and is significantly smaller in diameter. This factor is important to consider when looking at your fixture, because the two tubes are not interchangeable.

What does the F stand for in fluorescent bulbs?

F = type of lighting. 32 = wattage. T8 = shape. “F” stands for fluorescent, which is the type of lighting.

Which is brighter T12 or T8?

The Standard T12 lamp produces 2,650 initial lumens per lamp. The standard T8 produces 2,800 initial lumens per lamp, 6% brighter. But the standard T12 lamp produces 2,300 design lumens and the T8 produces 2,660 design lumens. … Design Lumens are the average lumen output of the lamp after 40% of its rated life.

Can you replace T5 with T8?

T5 lamps cannot replace T12 or T8 lamps because of differences in physical and electrical characteristics. T5 lamps come in different lengths than T8 and T12 lamps. A nominal 4-foot T5 lamp is actually shorter than an equivalent T8 lamp [1149 millimeters (45.23 inches) in total].
