Can you walk the cup with a Pyrex cup

Depending on the joint configuration, operators need to adjust the size of cup used for the root pass, but in most cases (and for the sake of this discussion), a number six (3/8 inch) cup would be appropriate.

What size cup is best for walking the cup?

Depending on the joint configuration, operators need to adjust the size of cup used for the root pass, but in most cases (and for the sake of this discussion), a number six (3/8 inch) cup would be appropriate.

What is walking a cup?

Essentially walking the cup is anytime a welder places the cup of their torch against their material. It’s almost exclusive to TIG welding and largely for welding pipe or tee joints.

What are Pyrex TIG cups used for?

With an Arc-Zone Gas Saver Pro™ Kit you can produce high-quality welds on a consistent basis for a variety of TIG welding applications. The Pyrex glass nozzle offers excellent visibility of the weld puddle and the tungsten electrode– ideal for inside corners, pipe and tube clusters etc.

Are TIG cups easily broken?

TIG Gas Cups- Standard Ceramic Gas Cups are quite durable and really won’t go bad if care for. We’ve found that the most common damage to the cups is dropping the torch or it swinging against a work bench and shattering the cup.

How do I know what size TIG torch I need?

TIG torches come in a number of set sizes: 9, 17, 18 & 26. These, generally, are in numerical order, in that 9 is the smallest size torch and 26 is the largest. ‘Generally,’ because the size 20 torch is the water-cooled version of the size 9 (but UNIMIG doesn’t sell that torch).

What do different size TIG cups do?

For example, the smaller the pipe diameter, the shorter the selected nozzle. Larger gas nozzle diameter – more shielding gas cover: The diameter of the gas nozzle, or its opening, determines the size of the area around the weld seam that will be covered by shielding gas.

Do you push or pull when TIG welding?

With TIG welding, use argon gas whether joining stainless steel, aluminum or steel. While push and pull both work well for MIG welding, with TIG, always use the push method.

What is a Heliarc?

Heliarc, which is also known as Gas Tungsten Arc Welding (GTAW) or more popular Tungsten Inert Gas (TIG) welding, was perfected in 1941 by Russell Meredith. For the welding process, a welder will make an arc in between the base metal and the tungsten electrode (the non-consumable).

How long does a TIG rod last?

As a general rule, welding rods that are kept in ideal conditions should last upwards of 3 years. The life of an electrode will vary by the material as well as manufacturer, but most recommend switching for new ones after five years.

Article first time published on

What size TIG Cup should I use?

The standard #5 cup is a go to cup for a lot of really good tig welders. One of the main benefits to using a #5 cup is argon savings. a setting of only 12-14 cfh works in most situations. For me, the #5 cups work great for 1/8″ and thinner aluminum.

What are TIG nozzles made of?

Gas cups (also known as nozzles) used in TIG welding are manufactured from ceramic materials of which there are two main types; Aluminum Oxide (pink color) and Aluminum Silicate (white or gray color).

What makes a good TIG torch?

The TIG welding torch needs to be rated to at least the same amperage as the welder, preferably higher. So if your TIG machine is rated at 250 amps, you need a torch with at least a 250-amp rating. Otherwise, it’s going to overheat, causing a failure and possibly even burning you.

How do I know what type of TIG torch I have?

Most tig torch manufacturers stamp a model number on the neck of the torch. The numbers are often preceded by letters, WP, SR, ER for example. These letters can usually be ignored as it is the number that is important when selecting the correct parts from this section.

What is a 17 series TIG torch?

Air Cooled Torch Models A #24 torch is a gas cooled torch capable of only 80 amps. It is compact but less common due to its limited amperage range – 80 amps will only handle very light TIG welding. … A #17 torch is a gas cooled torch capable of 150 amps.

What is the method of welding?

Welding is a fabrication process whereby two or more parts are fused together by means of heat, pressure or both forming a join as the parts cool. Welding is usually used on metals and thermoplastics but can also be used on wood. The completed welded joint may be referred to as a weldment.

Why do welds turn blue?

On stainless steel, for example, any color in the weld or HAZ shows that an oxide layer has formed, which can affect corrosion resistance. The darker the color is, the thicker the oxidization. The colors follow a predictable pattern, from chrome to straw to gold to blue to purple. … Corrosion resistance.

What's the difference between Tig and Heliarc?

TIG (Tungsten Inert Gas) and Heliarc welding are names for the same type of welding, in which an arc is produced with a non-consumable tungsten electrode. … However, the extra work pays off, as the welder has much more control over the strength and quality of the welds.

When was TIG invented?

After decades of development gas tungsten arc welding (GTAW), widely recognized as TIG welding, was finally perfected by Russel Meredith and patented in 1942.

Can you weld aluminum with DCEN?

DCEN aluminum GTAW provides significantly more penetration than AC, but you need to use 100 percent helium shielding gas to make the process stable. … DC GTAW can work very well on aluminum, so don’t be afraid to try it. Just be aware that the technique is different than that used for AC.

What direction do you TIG weld?

1. The angle of the torch should be 15 to 20 degrees away from the direction of travel. …
2. The filler metal should be brought in at as low an angle as possible to help avoid touching the tungsten electrode and contaminating it.
