How can we improve the performance of joiner transformation in Informatica

Designate the master source as the source with fewer duplicate key values. … Designate the master source as the source with fewer rows. … Perform joins in a database when possible. … Join sorted data when possible.

Which one is better performance wise joiner or lookup in Informatica?

In case of Flat file, generally, sorted joiner is more effective than lookup, because sorted joiner uses join conditions and caches less rows. … In case of database, lookup can be effective if the database can return sorted data fast and the amount of data is small, because lookup can create whole cache in memory.

How do you handle performance issues in Informatica?

Optimize the target. …
Optimize the source. …
Optimize the mapping. …
Optimize the transformation. …
Optimize the session. …
Optimize the grid deployments. …
Optimize the PowerCenter components. …
Optimize the system.

How can we improve the performance of filter transformation in Informatica?

Avoid complex expressions in filter conditions. Avoid using complex expressions in filter conditions. To optimize Filter transformations, use simple integer or true/false expressions in the filter condition. The Filter transformation filters data within a mapping.

How does Informatica improve target performance?

Moving the target database into the server system may improve session performance. Staging areas: If we use staging areas, then force the Informatica server to perform multiple data passes. Removing of staging areas can improve the session performance. Use the staging area only when it is mandatory.

What is the difference between lookup and joiner transformation?

Joiner is used for joining two homogeneous or heterogeneous sources residing at different locations. Lookup is used to look-up the data. Joiner is an Active Transformation. Lookup transformation is a Passive transformation.

What is the difference between union and joiner transformation in Informatica?

A Union transformation can merge data from multiple sources but does not combine data based on a join condition or remove duplicate rows, like a Joiner transformation. … The Joiner transformation supports Normal, Right Outer, Left Outer, and Full Outer JOINs. Include multiple input groups. Yes.

What is performance bottleneck in Informatica?

Bottleneck is the reason by which the performance of the Informatica ETL process gets slower. There are different types of Bottlenecks in Informatica. It can happen either while writing to the target or while reading from source and many more.

How can mapping performance be improved?

To maximize session performance, keep the Filter transformation as close as possible to the sources in the mapping. Rather than passing rows that you plan to discard through the mapping, you can filter out unwanted data early in the flow of data from sources to targets.

Why we use pushdown optimization in Informatica?

Pushdown Optimization is use to increase data processing performance extremely. Always processing data on database level is faster than processing data in Informatica level. … Pushdown Optimization is a concept of push Informatica transformation logic on source or target when they are database table.

Article first time published on

How can lookup transformation improve performance?

To improve performance, create a filter condition to reduce the number of lookup rows retrieved from the source when the lookup cache is built. Index the lookup table. The Data Integration Service needs to query, sort, and compare values in the lookup condition columns.

How do you increase bottleneck source in Informatica?

Add a Filter transformation to the mapping. Add the Filter transofrmation after the source. …
Create a read test mapping. Make a copy of the mapping but remove all the transformations, joins, or queries. …
Run the read query directly against the source database. Copy the read query from the mapping log.

What is update strategy transformation in Informatica?

Update Strategy Transformation is an active and connected transformation, which is used for Inserting, Updating, Deleting and rejecting the records in the target table. The target table should contain Primary key.

What is Joiner transformation?

Joiner transformation is an active and connected transformation. It provides the option of creating joins in the Informatica. By using the joiner transformation, the created joins are similar to the joins in databases. The joiner transformation is used to join two heterogeneous sources.

What is rank transformation in Informatica?

The Rank transformation selects the top or bottom range of data. Use the Rank transformation to return the largest or smallest numeric values in a group. You can also use the Rank transformation to return strings at the top or bottom of the mapping sort order.

What is normalizer transformation in Informatica?

The Normalizer transformation is an active transformation that transforms one incoming row into multiple output rows. … When the Normalizer transformation returns multiple rows from an incoming row, it returns duplicate data for single-occurring incoming columns.

How do I Union two tables in Informatica?

Go the mapping designer, create a new mapping or open an existing mapping.
Go to the toolbar-> click on Transformations->Create.
Select the union transformation and enter the name. …
Go to the Groups Tab and then add a group for each source you want to merge.

How do I join 3 tables in Informatica?

To join more than two sources in a mapping, you can use multiple Joiner transformations. You can join the output from the Joiner transformation with another source pipeline. You can add Joiner transformations to the mapping until you join all source pipelines.

What types of transformation ports are supported?

Active Transformations.
Passive Transformations.
Unconnected Transformations.
Multi-Strategy Transformations.
Transformation Descriptions.

How does Joiner cache work in Informatica?

The Integration Service uses cache memory to process Joiner transformations. When you run a session, the Integration Service reads rows from the master and detail sources concurrently and builds index and data caches based on the master rows.

What is persistent cache in Informatica?

What is Persistent Cache? Lookups are cached by default in Informatica. This means that Informatica by default brings in the entire data of the lookup table from database server to Informatica Server as a part of lookup cache building activity during session run.

What is cache in Informatica?

When a lookup is cached: Informatica queries the database, brings the whole set of rows to the Informatica server and stores in a cache file. When this lookup is called next time, Informatica uses the file cached. As a result, Informatica saves the time and the resources to hit the database again.

What are the optimization techniques in Informatica?

Pushdown optimization.
Early projection optimization.
Early selection optimization.
Branch pruning optimization.
Push-into optimization.
Predicate optimization.
Global predicate optimization.
Cost-based optimization.

How do you find bottlenecks in Informatica?

Run test sessions. You can configure a test session to read from a flat file source or to write to a flat file target to identify source and target bottlenecks.
Analyze performance details. …
Analyze thread statistics. …
Monitor system performance.

What is a mapplet in Informatica?

A mapplet is a reusable object containing a set of transformations that you can use in multiple mappings. Use a mapplet in a mapping. Or, validate the mapplet as a rule. Transformations in a mapplet can be reusable or non-reusable. If you add a Sequence Generator transformation to a mapplet, it must be reusable.

How do you resolve a target bottleneck in Informatica?

Dropping Indexes and Key Constraints.
Use constraint-based loading only if necessary.
Increase Database Checkpoint Intervals (Decrease the number of checkpoints).
Configure the flat file target that is local to the Integration Service process node.

How is busy percentage calculated in Informatica?

The busy percentage is calculated: (run time idle time) / (run time * 100). Each session has a minimum of three threads: reader thread. transformation thread.

What are bottlenecks in business?

A bottleneck is a point of congestion in a production system (such as an assembly line or a computer network) that occurs when workloads arrive too quickly for the production process to handle. … Companies are more at risk for bottlenecks when they start the production process for a new product.

How increase DTM buffer size in Informatica?

To increase the DTM buffer size, open the session properties and click the Properties tab. Edit the DTM Buffer Size property in the Performance settings. Increase the DTM Buffer Size property by multiples of the buffer block size.

What is push down Optimisation in Informatica?

Pushdown optimization is a concept using which you can push the transformation logic on the source or target database side. … When you use the SQL override, the session performance is enhanced, as processing the data at a database level is faster compared to processing the data in Informatica.

How remove duplicates from Informatica flat file?

Load the data to a temp table and then just select the distinct records.
Use a sorter or aggregator transformation and then select the distinct option (In the properties tab if I remember correctly)
Use the dynamic lookup which will only insert records into the cache if they have not been inserted already.
