How do I replace the heating element in my Maytag dryer

For Maytag dryers, it’s common for the price of a heating element to be around $40. You could easily find a heating element for a Whirlpool dryer also around $40.

How much does it cost to replace a heating element in a Maytag dryer?

For Maytag dryers, it’s common for the price of a heating element to be around $40. You could easily find a heating element for a Whirlpool dryer also around $40.

How do you fix a Maytag dryer that won't heat?

1. Check the incoming power. …
2. Check your dryer settings. …
3. Check the exhaust vent. …
4. Faulty thermal fuse. …
5. Defective heating element. …
6. Faulty high limit thermostat. …
7. Faulty cycling thermostat. …
8. Faulty igniter.

How can you tell if a dryer heating element is bad?

Inspect the metal wire coil for any breaks in the wire. If the wire is solid and has no breaks in it, the heating element should be good. If the wire has a break in it, the heating element is defective.

Is it worth replacing heating element in dryer?

If your dryer’s heating element burns out more than once within a year or two, the thermal fuse, which is supposed to protect it, is probably defective, so it’s a good idea to replace it. The temperature in the heating chamber may also be too high, and that may be caused by poor venting.

Why is my dryer getting hot but not drying?

There are several reasons why the dryer is heating up, but still not drying clothes and it might take several hours to finally get them dry. The reasons are: clogged exhaust vent, faulty heating element, malfunctioned cycling thermostat or clogged lint trap.

What causes a heating element to burn out in a dryer?

A dryer’s heating element operates on the same principle as the coil in an electric heater. It consists of an uninsulated metal conductor and when an electric current passes through it, its resistance to the flow of electricity makes it heat up. If the coil gets too hot, it burns out.

Why does my Maytag dryer take so long to dry?

Clogged dryer vents are probably the most common cause when your Maytag dryer takes too long. … When this happens, airflow will be restricted, and you’ll notice your dryer leaving clothes damp. To prevent vent clogs, clean out your dryer vent annually, and assess the vent for pinches or crimps that also restrict airflow.

Where is the dryer heating element located?

Depending on the model of dryer, the heating element is located either behind the dryer drum inside the dryer cabinet, or behind a panel on the back of the dryer.

Do Maytag dryers have a reset button?

Maytag dryers boast several features, including a high performance motor, reduced vibration, moisture sensors, wrinkle-prevention option, variable dry for different items and fabrics, and different temperature settings. One thing that Maytag dryers do not have, however, is a reset button.

Article first time published on

Why is my Maytag dryer blowing cold air?

With electrically heated dryers, the most common problems are a defective thermostat or an open heating element. … In some cases, the high-limit thermostat is a thermal fuse; if this thermal fuse has burned open, the dryer blows cold air. Thermal fuses do not reset, and need to be replaced.

How much does a dryer element cost?

How Much Does a Heating Element Cost for a Dryer? A new heating element is usually between $40 and $100. This part might cost as low as $30 and as high as $200 or more, depending on the type of dryer.

Where is the thermal fuse on a dryer?

The thermal fuse will be located somewhere by the exhaust vent on your dryer. You will be able to visually identify it by the two wires connecting to it. Removing the front of the dryer and removing the drum might be easier to access the fuse’s location.

How much does it cost to fix a dryer that won't heat?

Fixing a dryer that does not heat averages $100 to $350. The price for this repair depends on the problem. It might be a problem with the heating element or an issue with the thermostat or igniter when using a gas dryer.

How long should dryer heating element last?

The heating element can last between 8 and 18 years if the dryer is well-maintained and the vent and lint traps are clean. The heating element can burn out if the dryer is not kept well-maintained.

How do you know if an element is bad?

Touch a probe on the multitester to each screw on the element. If you get no reading, or a maximum reading, the element is bad. Elements do have some resistance, so a reading of 10-16 ohms is normal, with higher ohm readings for 3,500 watt elements and lower readings for 5,500 watt elements.

Is there a reset button on a clothes dryer?

Many dryers are equipped with a reset button on the control panel. If the motor won’t run, let the dryer cool for about ten minutes. Then push the reset button. If there are no problems with the motor, switches, or electrical system, this should restart the dryer.

Why is my dryer not drying my clothes completely?

Check the Air Vent and Duct Clogged air vents are a common cause for poor airflow in clothes dryer systems. One way to see if your dryer’s air vent is clogged is by turning on your dryer and going outside to feel the flow of air leaving the vent. If it’s slow and not very warm, your vent may be due for a good cleaning.

Why are my clothes still wet after the dryer?

A good airflow is the key for a dryer to work properly. If your clothes are still wet after a drying cycle it could mean that the Air Vent is clogged. To fix this problem, you will have to unplug the dryer and disconnect it from the vent. Once everything is disconnected, it’s time to vacuum the vent.

What happens when a thermal fuse blown on dryer?

A thermal fuse will blow when the temperature gets too high, not when it’s drawing too much current. … When it blows, the dryer stops generating heat. It’s necessary to replace it before the dryer will run again.

Should a dryer heating element glow red?

Occasionally, a red glow may be seen inside the dryer drum. This is normal. The glow is from the heating element and is most noticeable if the cycle has been interrupted to remove or add an article of clothing. … As the cycle nears the end, the element goes off.

How do you check the moisture sensor on a Maytag dryer?

1. Make sure the dryer is on the “auto-dry” setting.
2. Place several damp articles of clothing in the dryer and start a regular drying cycle.
3. If the dryer continues running after clothes are dry or stops when clothes are still damp, the sensors may not be functioning properly.

Why is my Maytag gas dryer not heating?

Always check the dryer venting when replacing a blown thermal fuse. … If a gas valve solenoid fails, the dryer won’t heat. To determine if one or more of the gas valve solenoids has failed, check the igniter. If the igniter glows and goes out but does not ignite the gas, the gas valve solenoid is defective.

How do you reset a Maytag?

1. Press the “Power/Cancel” button. …
2. Push the appropriate button to choose a new cycle.
3. Press “Start/Pause.” You have now reset your Maytag washer.

Where is the thermal fuse on a Maytag Bravo dryer?

This fuse is located on the exhaust duct. If the dryer overheats, the thermal fuse opens to cut off power to the dryer. The thermal fuse cannot be reset–if the thermal fuse is open, it must be replaced. Dryer thermal fuse located on the blower housing.
