How do you adjust a Toro 570z sprinkler head

Arc Adjustments To find the left stop position, rotate the nozzle turret clockwise (to the right) until it stops, then rotate the nozzle turret all the way back to the left. point to the adjustable right stop. When the rotor is set at 360°, it will continuously rotate in a clockwise direction.

How do you adjust an old Toro sprinkler head?

Arc Adjustments To find the left stop position, rotate the nozzle turret clockwise (to the right) until it stops, then rotate the nozzle turret all the way back to the left. point to the adjustable right stop. When the rotor is set at 360°, it will continuously rotate in a clockwise direction.

How do you adjust Toro 600 sprinkler heads?

Note: A small screwdriver or similar tool is required to depress adjustment button (located at top of drive assembly) when adjusting arc pattern. nozzle clockwise to desired amount of arc increase, then release adjustment button. DESIRED RIGHT TRAVEL LIMIT To Decrease Arc (A) Start with nozzle at right stop.

How do you adjust a 360 degree sprinkler head?

Insert the plastic key end of the Hunter wrench into the adjustment socket. While holding the nozzle turret at the right stop, turn the wrench clockwise. Each full 360° turn of the wrench will increase the arc 90°. Adjust to any arc between 40° and 360°.

How do you adjust Toro Super 700 sprinkler heads?

Press nozzle down to engage internal arc adjuster (gap removed). While pressing down, turn nozzle clockwise to add required arc. Pull nozzle up and release.

How do you adjust a Toro mini 8 sprinkler head?

Insert your Mini 8 rotor key into the radius adjustment screw. This is the small screw on the right side of the sprinkler head. Turn the key clockwise to reduce the radius or distance of water from the sprinkler head. Turn the key counterclockwise to increase the radius of water.

How do you adjust a Toro tr50 sprinkler head?

Watering Arc Adjustment Turn the arc adjustment ring to align the white arrow to the right side of the watering arc. The watering area is between the cap arrow and the adjustment ring arrow. This example is set to 180°. Turn the adjustment ring 90° to the left to decrease the arc.

How do you adjust the radius on a sprinkler head?

To adjust the throw radius simply insert a fine-tip flat-head screwdriver into the metal screw (located at the center of the head). Rotate clockwise to decrease the radius, and counter-clockwise to increase the radius. 1. To adjust the arc simply twist the center collar (adjustable from 0 to 360 degrees).

How do you fix a Toro sprinkler head?

Start digging by cutting straight into the turf with the shovel several inches from the sprinkler head. …
Continue digging the hole. …
Unscrew the head from the pipe.
Turn on the water for several seconds to flush out the pipe.
Screw the new head onto the pipe.
Turn on the water to test the sprinkler.

How do you adjust the direction of a pop up sprinkler head?

Turn the adjustment screw Using a wrench or a screwdriver, rotate the screw – clockwise to increase distance and counter-clockwise to decrease distance. While turning the adjustment screw, be sure to do so in small increments until you reach your desired distance.

Article first time published on

Why is my sprinkler head not rotating?

The most common reason for a sprinkler to stop rotating is the accumulation of debris in the filter. … When in operation, water turns a small turbine in the base of the sprinkler, which drives a series of gears that cause the head to rotate. The Hunter gear drive mechanism is sealed from dirt and debris.

How do you turn off a Toro sprinkler head?

Do what it takes to free up that tiny screw in the center of the head. Turn the tiny screw in the center head counter-clockwise with a screwdriver until it feels tight, which generally will take between a quarter and a half turn. Run your sprinkler system to make sure you have properly turned the head off.
