What is the purpose of a weeping tile

Weeping tiles, also known as drain tiles, are a type of pipe system used to collect and discharge underground water safely away from your foundation. Originally named when similar systems were designed with terracotta tiles, modern drain systems use plastic.

Are weeping tiles necessary?

Weeping tile is a necessary part of waterproofing a basement at new home construction stage. It collects pooling water at the base of the footing level and drains it to a sump pump before it builds enough pressure to push into the home.

What's the difference between weeping tile and French drain?

Using a similar concept to eliminating basement flooding, the French drain is placed about a foot below the ground’s surface. A gravel-filled trench is cut on a slight slope. Weeping tile is installed then a layer of gravel and coarse sand is placed on top.

Where do you put weeping tile?

They can be installed on along the perimeter of the foundation walls, from either the inside or the outside. These types of weeping tile are much more likely to clog with mud and debris. And if it’s been installed along the outside of the home, it will not be accessible without excavating the foundation.

How long do weeping tiles last?

What is the life expectancy? Perimeter drains or weeping tiles can last for decades. If properly installed, you can expect to have a problem free basement for a very long time. Older clay weeping tiles tended to deteriorate, and become clogged with soil and tree roots, but even these systems lasted for many years.

Do you need weeping tile around garage?

Weeping Tiles (aka French Drains, aka Perimeter Drains) around your garage collect the groundwater when the water table rises and diverts it to a safe discharge point. They protect your garage foundation from damage and prevent groundwater from leaking and pooling onto the garage floor.

How deep do you put weeping tile?

Ensure that the top of the weeping tile pipe is about 6 inches below the surface of the ground.

What is the required diameter of weeping tile?

Minimum Size. Drain tile or pipe used for foundation drainage shall be not less than 100 mm in diam.

Does every house have weeping tile?

Most homes built prior to the 1960’s do not have a weeping tile drainage system. … To find out if your home has weeping tile, look in the catch basin (basement floor drain) or sump pump pit. If you have a weeping tile drainage system, you will see a series of 6 inch pipes coming from different directions under the floor.

Can downspouts connected to weeping tile?

When a downspout is connected to a weeping tile, substantial rainfall funnelled into one underground location can overwhelm the drainage system and result in backups, basement flooding and foundation damage. In some towns and cities, the downspout cannot be connected to the municipal sewer system by law.

Article first time published on

Can weeping tile get clogged?

Over time, your home’s weeping tile system can become clogged with sediments, soil and more. However, having a clogged weeping tile system does not always mean that you need a replacement! High-pressure flushing provides an effective, more cost-efficient alternative.

How do you tell if your weeping tile is clogged?

One of the most obvious signs of a clog is soggy soil around your home. If your tile isn’t working, it can’t drain the water away, turning the ground very soft with pooling water. Other signs will show up when the problem becomes worse and affect the inside your basement.

Can I connect weeping tile to sewer?

A weeping tile that is directly connected to your home’s sanitary sewer lateral increases the amount of water that enters the municipal sewer system during a heavy rainfall.

Does interior weeping tile work?

Compared to exterior waterproofing, an interior weeping tile system is much less expensive (since no excavation is involved) and is a proven, highly effective basement waterproofing method. Interior perimeter drainage systems are used mainly for waterproofing concrete block / cinder block foundation walls.

How do you fix a clogged weeping tile?

1. Fill the basin and weeping tile with water and liquid soap. Do not allow it to overflow.
2. Leave the soapy water for 30 mins to neutralize the odor.
3. Pull the plunger out to allow the water to drain.
4. Repeat several times and then rinse with clean water.

What is a French drain and what does it do?

A French drain is a trench filled with a perforated pipe and gravel that allows water to drain naturally from your yard. Depending on the size of your yard and the scale of your drainage issue, you can purchase the pipes and equipment to create a French drain yourself.

How do drainage tiles work?

Drain tile is essentially a network of porous pipes that run alongside your foundation. … The pipes run through a network that leads to a sump pump to drive the water away, or they go through a downward sloping drain system that leads away from your home to the surface where the water can safely drain away.

How do I know if my house has drain tiles?

While drain tiles are a simple solution to keep water away from foundations, dirt and tree roots can interfere with their efficient operation. Signs of a plugged drain tile system include water entering the basement or crawl space, lush grass growth, puddles, or a sinkhole forming along the line of piping.

Do older homes have weeping tiles?

In older homes, you’ll generally find weeping tile made from clay, while these days, it’s usually made from perforated flex piping that allows water to enter. If your basement has water, a damaged weeping tile could be a culprit.

Where does the water from my gutters go?

Rain gutters collect the water. Downspouts carry the water to the ground. Water on the street flows downhill into street gutters, the place where the sidewalk and the street meet. Street gutters carry water to storm drains that let water fall beneath the street.

Why do my gutters drain into the ground?

With debris clogging up the underground drainage, water is no longer able to enter and flow through. Many homes have gutters and downspouts that are unprotected. These unprotected gutters let debris of all sizes enter the gutter, where it travels down the downspout and into the underground pipes.

What does a downspout empty into?

Buried downspouts empty into a French drain which carries the water away from the building to drain into the ground wherever the pipe ends. Some people prefer the French drain empties into a sewer instead of the curb or side of the street.

Can you clean out drain tile?

Foundation tiles clogged with dirt or debris will begin to drain the water slowly or not at all. You can usually clean the foundation drain tile using a sewer snake, routing out the dirt that has gathered in the pipes to make the way clear again for proper water drainage.

Can you have drain tile without a sump pump?

If you have a drain tile system installed in your home, don’t take chances. If you don’t have a pump, get one installed. Its the only way that system can operate as designed to keep your basement dry. The cost of a pump and discharge pipe is cheap insurance and will cost a lot less than dealing with a wet basement.

How much does it cost to clean pipes?

Nationwide, the average cost to clean a clogged drain is $130-$180. This covers both the cost to find the clog and clear the drain. Most plumbing companies will charge a flat rate of $50 – $150 to come out, which also covers the first hour of work.
