What kind of foam do you use under concrete slab

Two of the rigid foam insulations most commonly used below grade and under slabs are expanded polystyrene (EPS) and extruded polystyrene (XPS). Although both are closed cell insulations, they perform very differently over the long term.

Should you put foam under concrete slab?

For under-slab applications, the rigid foam insulation typically should be installed over a gravel base, with a poly vapor diffusion retarder between the gravel and insulation. … As such, it provides a cost-effective way to insulate building foundations, and under slabs.

What type of insulation can be installed under a concrete floor slab?

Polyurethane foam insulation is the best option for underslab insulation for suspended concrete slabs. The underside of suspended Concrete slabs need to be insulated for various reasons, mainly energy efficiency and condensation control.

How thick should foam be under concrete slab?

A 2-inch layer of rigid foam insulation is forty times more efficient at trapping heat than concrete alone.

What is best to put under concrete?

What is the Best Base for a Concrete Slab? Most people build a driveway or a patio so in that case, a good choice would be a mix of coarse and fine aggregate which will create a compactable base. Overall, a mix of crushed stone and stone dust is the best base material for any concrete flatwork.

How thick should slab insulation be?

The Thickness of Concrete Floor Insulation The key is that you’ll want your insulation to be at least two inches thick unless it’s an insulation type with a high rating.

What is the best insulation for concrete floor?

EPS is a good choice for insulating a concrete floor because it has a long term R-value, alongside a consistent level of thermal resistance, and it is produced in easy to manage sheets to allow easy installation.

Which is better EPS or XPS?

Due to its physical properties, XPS has a higher r-value than EPS at 4.7 per inch. … However, the blowing agents used in the manufacturing process were known to deplete overtime, reducing the insulation value.

How do I keep my concrete floor warm?

A layer of dense foam padding under the laminate can help warm up the floor. In slab situations, raising the subfloor off the concrete with a layer of plywood over sleeper strips before installing the surface flooring can also make it warmer on the feet.

How do you insulate under concrete floor?

There are two ways to handle insulating concrete floors. You can attach wood sleepers to the floor, fill the gaps with rigid-foam insulation, and then apply a subfloor and finish flooring. Or, as demonstrated here, you can cover the slab with rigid-foam insulation, add two layers of plywood, and then add the.

Article first time published on

How do you install rigid foam insulation on a concrete floor?

Apply two coats of epoxy paint over the existing slab. The area should be clear of dust and debris. Install rigid foam insulation (XPS or EPS Type II) with the seams taped (see Figure 3). Install 1×4 furring strips at 16 inches o.c. and attach them to the concrete slab through the rigid foam insulation.

How thick should a concrete base be?

Standard concrete floor slab thickness in residential construction is 4 inches. Five to six inches is recommended if the concrete will receive occasional heavy loads, such as motor homes or garbage trucks.

Can I use gravel as a sub base?

If your builder uses the gravel he may find it will dissipate too easily into the ground and will spend more time and money to get the levels needed. I would not advise using the gravel. A well constructed base means your drive will never get sink holes.

How much insulation do I need under a slab?

1 a minimum R-10 (in units of h·ft²·°F/Btu) perimeter insulation but if it’s heated an additional R-5 is required with the height/depth subject to climate zone. For commercial buildings, edge insulation of R 7.5 to R-20 is required for all heated slabs again depending on climate zone.

Can you put Styrofoam under concrete?

Finally, some contractors in cold climates began installing a continuous horizontal layer of rigid foam insulation under their concrete slabs. The foam layer isolates the room-temperature slab from the cold soil under the slab.

How do you insulate a concrete floor before pouring?

1. Excavate the area under the slab to 12 inches below the planned level of the top of the slab. …
2. Place 4 inches of gravel in the excavation. …
3. Lay a layer of 6 mm plastic across the floor. …
4. Place 2-inch thick pieces of rigid Styrofoam insulation on top of the plastic sheeting.

What is sub slab insulation?

Sub slab insulation allows the concrete slab floor to remain a comfortable temperature instead of transferring most of its heat to the earth below. This insulation is specifically designed with a density appropriate for use below concrete slabs and is therefore capable of bearing structural loads.

Do you need underlay on concrete floors?

Regardless of your subfloor, you always need to use a thin underlay with laminate flooring. But with concrete, it also needs to have a moisture barrier. … To prevent the moisture from ever reaching the laminate, you need an underlay with a damp proof membrane.

How do you insulate an old concrete slab?

1. 1 . Prepare the Slab. Interra panels must sit flush against the slab. …
2. 2 . Install a Moisture Barrier. …
3. 3 . Install Wood Strapping. …
4. 4 . Place Interra Panels. …
5. 5 . Lay The Subfloor.

How much heat is lost through a concrete floor?

While the two flooring types are very different, the general estimated heat loss for all flooring is around 10%.

What is XPS underlay?

An Xps foam underlay is an eco-friendly, lightweight insulation board, used not only in flooring underlayment, but also in a vast variety of other applications in the construction industry including: wall insulation, perimeter insulation, under concrete slabs and roofs and swimming pool insulation.

What is the difference between EPS and XPS foam?

XPS is manufactured in a continuous extrusion process that produces a closed cell form of foam insulation. EPS, on the other hand, is manufactured by expanding spherical beads in a mold and then using heat and pressure to fuse the beads together.

What is the R-value of 2 inch foam board?

A wall utilizing STYROFOAM T-MASS Technology with a 2-inch exterior layer and a 4-inch interior layer of concrete along with a 2-inch layer of STYROFOAM extruded polystyrene insulation would result in a material R-value of approximately 11.33.

Is it worth insulating under a slab?

With a slab-on-grade, the difference is you use ‘insulation’ to insulate, rather than dirt. This effectively moves the frost line from 4 feet down to just 6 inches, problem solved. Building above grade on a slab can be a much cheaper starting place than a basement, and leads to a more comfortable and durable home.

What is the minimum thickness for floor insulation?

Building Regulations would require at least 70 mm of high-performance foam insulation, or 150 mm of mineral wool, (although this will vary depending on floor type, construction, shape and size).

How many inches of gravel do you need for a concrete slab?

How Much Gravel Do You Put Under a Concrete Slab? You will need 3 inches of gravel under a concrete slab that is 4 inches thick. More gravel is better, but 3 inches is the minimum amount of gravel you should have with a 4” slab. Use ¾” washed and screened gravel, then compact it to level.

How much weight can a 4 inch slab of concrete hold?

Typically we like to limit the weight to about 40 lb/sqft on an unknown 4″ slab. In most cases you can go to 80 lb/sqft in isolated spots, but unless you know roughly what the soil bearing and reinforcing is for that slab you might be looking at cracking.

How many yards of concrete do I need for a 24x24 slab?

For example, for a concrete slab that is 24′ X 24′ X 4”, simply enter 4 in the Thickness/Depth field, 24 in the Width field, and 24 in the Length field. Click “Calculate”. Your answer should be 7.11 yards. Note: The Concrete Volume Calculator can also be used to determine yardage for aggregate products.

Can I use old slabs as sub-base?

It will be fine.

Can I use concrete as a sub-base?

Any potential ‘soft-spots’ in the subgrade can allow the concrete to sink from the center or turn up from the edges. Owing to its inflexibility, the concrete slabs can crack. As concrete is highly compressed and heavy, it may crack under its own weight if not provided a suitable sub-base.

Can I use sand as a sub-base?

Simply put, sand isn’t sturdy enough to work well as a subbase for something like a driveway. With areas like patios, which don’t require a ton of load-bearing, sand as a subbase works fine, though it’s not as reliable as gravel.
