What size notched trowel for Kerdi

A 1/4″ x 3/16″ (6 mm x 5 mm) V-notched trowel or the Schluter™-KERDI-TROWEL is recommended.

What size trowel do I use for Schluter KERDI?

A 1/4″ x 3/16″ (6 mm x 5 mm) V-notched trowel or the Schluter™-KERDI-TROWEL is recommended.

How far apart are the screws on Kerdi board?

Only use Schluter screws and washers to attach KERDI-BOARD to the studs. Furthermore, the maximum on-center spacing for the screws and washers is 12 inches.

Why can't you use modified thinset on KERDI?

Modified thinset mortars aren’t recommended for use with Kerdi because they must dry out to gain strength, whereas the membrane inhibits drying, which can lead to unpredictable results. … Schluter’s recommendation is to use unmodified thinset mortar when installing Kerdi over most shower substrates.

What size trowel should I use for 12x12 tile?

Floor tiles measuring 12 by 12 inches are considered standard, requiring a notched trowel size of either 1/4 inch by 3/8 inch or 1/2 inch by 1/2 inch.

Can I use RedGuard with KERDI?

Can you Redgard over Kerdi? No, it won’t interfere with the performance or adversely effect it. RedGuard is not harder to adhere to. There is no reason to use both products although it can be easier to use the RedGuard in corners and niches without the build up you can get with kerdi.

What size trowel do I need for 12x24 tile?

Tools and Tips for The Actual Mortar Application Process for 12×24 Tile. As I mentioned before, mix your mortar to be a little bit on the thick side, and use a 1/2 inch notched trowel to apply it to the subfloor where you want your tile.

Can you tile over Kerdi board?

For most installations of KERDI-BOARD, tile can be installed right away. Exceptions include curved wall areas and non-bearing partition wall systems. In these applications, the tiles can be installed once the bonding materials have cured sufficiently to stabilize the KERDI-BOARD assembly.

Which Mapei Thinset is unmodified?

Keraset: This is Mapei’s mid-range unmodified.

What mortar do you use for Kerdi membrane?

Schluter SET™, ALL-SET™, FAST-SET™ or an unmodified thin-set mortar must be used to construct all KERDI seams to ensure watertightperformance of the system.

Article first time published on

How thick should Thinset be under Ditra?

The Ditra membrane itself is 1/8″ thick, and Schluter recommends using a size 1/4″x3/16″ V notched or Square notch trowel 11/64″x11/64″ between the subfloor to Ditra, and 1/4″x3/8″ square or U notched trowel between Ditra to the tile.

What consistency should Schluter all set be?

3. Following this procedure will produce the best workability and help ensure maximum open time and pot life. To install Schluter® membranes the mortar should be mixed to a fairly fluid consistency, but still able to hold a notch. Do not add more water after mixing.

Can KERDI-BOARD be installed directly to studs?

Whether you need to even-out an existing problematic substrate, install a solid backing directly on stud frame structures, or build custom elements such as pipe or column coverings, KERDI-BOARD makes it quick and easy. 1/2″ or 5/8″ (12.5 or 15 mm) for studs spaced at 16″ o.c. 3/4″ (19 mm) for studs spaced at 24″ o.c.

What size notched trowel for plank tile?

Typically for floor installations, a 1/4” square-notched trowel is the right tool for the job, but if your floor is rolling, uneven, or if you are working with very large tiles, it helps to use a trowel with larger notches. Recommended sizes are 3/8” and 1/2”, which are easy to find in most hardware stores.

How do you know what size trowel to use?

Finding the right trowel for the job is quite simple when you know that, generally speaking, the trowel size should match up to the tile size – the smaller the tile, the smaller the trowel; the larger the tile, the larger the trowel.

How thick is thinset for 12x12 tile?

The thinset layer beneath your 12×12 tiles should be thicker than ⅛ inch but should not exceed ¼ inch. For smooth-backed tiles and wall installations, use a ¼ X ⅜-inch square notched trowel. This will create a thinset layer just over ⅛-inch thick.

Can you use too much thinset?

In addition to producing an uneven surface, applying too much thinset can create costly cleanup headaches and add unnecessary time to a project.

Which direction should 12x24 tile be laid?

Its direction is similar to a brick wall, where the longer side is across the surface. This creates a more pleasant layout and makes the room look wider. For a much smaller space, such as the bathroom, it’s best to lay down the tiles the long way, where the longer side is set vertically.

How big should grout lines be for 12x24 tile?

A large tile, such as 12×24”, usually requires a 3/16” grout line, so it’s best to check the manufacturer’s recommendations to see how small you can go.

Can Kerdi be installed over plywood?

The Kerdi membrane system requires a 2” overlap at all seams; either with the membrane itself overlapping adjacent piece or with the use of Kerdi-Band tape. … Since thin-set mortar works over almost any substrate, the Kerdi system can be used over drywall, plywood, or the various cement boards mentioned above.

Can you use Kerdi niche with cement board?

Yes. The Schluter niche is by itself waterproof. The cement board is most definitely not. It would be recommended to Schluter fabric over the entire area, or put a couple layers of aqua guard or redguard over the cement board.

What sizes does Kerdi board come in?

With the available panel thicknesses of 3/16″, 3/8″, 1/2″, 5/8″, 3/4″, 1″, 1-1/2″, and 2″ (5, 9, 12.5, 15, 19, 25, 38, and 50 mm), KERDI-BOARD allows the installer to prepare and create a broad range of substrates and building elements for the installation of ceramic and natural stone tile that are flat, level, plumb, …

Is Mapei premium mortar modified?

Polymer-modified, cement-based mortars such as MAPEI’s Large Tile & Stone Mortar are generally recommended for installing tile over radiant-heat systems. Refer to the written instructions of the radiant-heat manufacturer for recommendations of cement-based mortars.

What is the difference between Schluter set and all set?

Schluter ALL-SET® is a specialized modified thin-set mortar specifically formulated for use with Schluter® membranes and boards. … Schluter SET® is a premium unmodified thin-set mortar specifically formulated to use with Schluter® membranes and boards.

Can I use modified thinset on Kerdi membrane?

In general, modified thin-set mortar is not recommended to set ceramic and stone tile, including large format tiles, over the KERDI membrane. Modified thin-set mortars must dry for the polymers to coalesce and form a hard film in order to gain strength.

Can I use modified thinset over Schluter?

Schluter-Systems requires the use of Schluter SET™ , ALL-SET™ , FAST-SET™, or an unmodified thin-set mortar meeting the requirements of ANSI A118. … In general, we don’t recommend the use of modified thin-set mortar to set tile over the membranes because these mortars must air dry to cure properly.

Is thinset mortar waterproof?

Thinset is designed to adhere well in a thin layer that’s typically not greater than 3/16″ thick. … Although thin-set is not waterproof, it is isn’t water soluble. When moisture is present, it will not return to a liquefied state as mastic would.

Do I need modified or unmodified thinset?

Modified thinset is the product of choice for most tile installations because of its increased strength and bonding with minimal shrinkage, which means a reduced chance of cracks forming in the tile. WarmlyYours Radiant Heating recommends modified thinset mortar for nearly all tile and stone installations.

How thick is Kerdi membrane with thinset?

The material is physiologically safe and does not require special disposal. KERDI is 8-mil thick and has a water vapor permeance of 0.90 perms, when tested according to ASTM E96, using Procedure E at 90% relative humidity.

What happens if thinset is too thick?

In addition to producing an uneven surface, applying too much thinset can create costly cleanup headaches and add unnecessary time to a project. Simple installation rules eliminate the possibility of this potential problem.

Is Schluter Kerdi worth it?

Great product. It takes a little longer than the traditional mud shower bed and water-proofing methods, but it is worth it. … My shower is water-tight, and the sloped floor drains water perfectly. The finished product looks great.
