Where is the drain hole on Whirlpool refrigerator

Inside your refrigerator and freezer compartments, typically near the back wall, is a small indentation. This is the defrost drain, which takes water and ice that accumulates on the walls of the refrigerator and freezer and drains it down to the drain pan on the bottom of the unit.

How do I find the drain hole in my refrigerator?

On most refrigerators the defrost drain tube and drain hole is located inside the freezer at the bottom back. Look in the freezer near the bottom and locate the drain tube and the drain hole. There may be a panel made from plastic that covers the drain tube and hole.

Where is the freezer drain in a Whirlpool refrigerator?

Where is the defrost drain on a Whirlpool refrigerator? It’s typically located on the freezer’s rear wall. Given this location, sometimes the defrost drain becomes clogged with ice or food particles, causing leaks that form frost.

Where is the defrost drain on a Whirlpool side by side refrigerator?

1. Models with a defrost drain hole located on the back wall of the freezer just up from where the floor slopes up to the back, in the center.
2. Models with a plastic panel held in place by a screw.

Why does my Whirlpool refrigerator have water in the bottom?

If your fridge has water pooling at the bottom, the defrost tube is your MOST likely suspect. Your defrost tube is what carries the water all the way down to the drain pan where it eventually evaporates. When working correctly, it helps make sure your fridge has a smooth defrost cycle.

Why is there standing water in the bottom of my refrigerator under crisper drawers?

When the freezer in a top-mount refrigerator defrosts, water drains down through a defrost tube into a drain pan and eventually evaporates. If the defrost drain tube is clogged with ice or gunk, the water can’t drain down the tube. Instead, it collects in a puddle under the crisper drawers.

How do you unclog a freezer drain?

Clear the ice from the drain hole with a screwdriver or a piece of stiff wire. Fill a basting syringe with warm water. Place the end of the syringe into the drain hole and squeeze the bulb on the syringe to force the water into the drain hole. This removes any remaining ice from the drain.

Where is the drain tube on a Whirlpool side-by-side refrigerator?

Whirlpool Drain Location If your Whirlpool refrigerator drain tube is clogged, you’ll probably have to access it from behind the appliance. Don’t be daunted by the jumble of tubes and wires you’ll see when you remove the evaporator coil panel. It’s right there under the evaporator coil.

Why is my refrigerator drain pan full of water?

Excessive water flowing into the drip pan can be caused by high ambient humidity. It can also be caused by a leak in the door gaskets or the ice dispenser if your refrigerator dispenses ice through the door. Frequent opening of the refrigerator or freezer door can also cause this problem.

Where is the drain hole on a side-by-side refrigerator?

Some Side-by-Side refrigerator models have a defrost drain hole located on the interior back wall of the freezer compartment. It is just up from where the floor slopes up to the back wall, in the center. In some models it is behind a plastic panel along the back wall and is held in place by a screw.

Article first time published on

Why is my Whirlpool side-by-side refrigerator leaking water?

If the defrost drain is frozen, the water will overflow the drain trough and drip down to the bottom of the compartment. This water can eventually leak onto the floor. Check the defrost drain to determine if it is clogged or frozen. … In addition, flush the drain with hot water to ensure that it is clear of debris.

Where is freezer drain hole?

The drain hole is usually located at the back wall of the freezer on the panel. On some refrigerator/freezers a plastic panel covers the drain hole. Remove the screw(s) and the panel to access the drain hole.

How much water should be in a refrigerator drain pan?

The front needs to be a ¼ to ½ inch higher than the back. This is required to allow the coolant to flow correctly.

Where is the drain hole located on a Frigidaire refrigerator?

Defrost Drain Is Clogged Where is the defrost drain on a Frigidaire refrigerator? Most are located behind the refrigerator’s rear panel, near the evaporator coils.

Why is my side by side freezer leaking water inside?

A likely cause of leaking in the freezer is a clogged defrost drain, which is where water from the defrost cycle is removed from the freezer into the drain pan below. If the defrost drain is clogged, this water cannot drain and ends up pooling inside the freezer or leaking out.

Why is my Whirlpool water dispenser leaking?

Trapped Air If your refrigerator water dispenser is dripping water, it could be because there is air trapped in the water line that is causing a build up of pressure that is forcing some water to seep through the dispenser opening. You should purge the tank if this is happening.

Why is water pooling in the bottom of my freezer?

Water will puddle at the bottom of the freezer when ice and frost melts inside the freezer. A sheet of ice at the bottom of the freezer will form when power is restored and the puddle freezes. Defrost the freezer to get rid of the sheet of ice in the bottom of the freezer.

Why does my Whirlpool refrigerator leak water from the freezer?

It’s leaking water Cause 1: A blocked defrost drain is one of the most common causes. This happens when food particles or other debris clog up the drain hose, which can lead to ice buildup and, eventually, water leaking out of the freezer and refrigerator.

Can you remove the drip tray?

If the drip pan is in the rear of the appliance, you should unscrew the back panel. … It’s positioned at the bottom of the refrigerator and you can easily pull it out by sliding a putty knife between the appliance and the kick panel itself. Once you remove it, locate the drip panel and try to pull it out.
